Welcome to OpEL Lab!     Proudly Serves The Courses...             ECE 2054   ECE 2074                    ECE 3074

     Contact Lab Manager

Lab Hours and Schedule of GTA coverage Enjoy the lab exercises. Exercise your curiosity. Please use the Queue to request TA assistance of any kind. (IMPORTANT NEWS: Web Hosting now requires 2-Factor authentication to the webpage!) Please see the schedule for open times and remember that validation days may be very busy. Lab policies - Student orientation, FAQs, location, rules, resources, GTAs, kit problems, etc GTA orientation - expectations of GTAs, FAQ's, etc Documentation: A&D Board - Information, Manual, Test procedure, wiring tips, bug fixes Velleman Scope care and use, scope software installation MY64 Digital Multimeter (DMM) use, maintenance, battery and fuse changing:   LTspice XVII - Linear Technologies download site with tutorials   Electronic Parts Kit Check List ECE Electronic Lab parts kits are distributed at the beginning of each semester for ECE 2054 and ECE 2074 This kit contains the diodes, transistors, ICs, LEDs, capacitors, inductors, resistors, and wires needed to build the experiments. Data Sheets - for components in the Electronis Parts Kit. Transformer test - how to test your green or red audio transformer (not included in current kits)

Lab-in-a-Box Kit Requirements: For most lab materials, we have arranged for one-stop shopping from Electronix Express, at competitive prices. Fully compatible parts from other vendors may be used. If you already own a fully compatible item, it is not necessary to purchase another one for a particular course. (Updated for Spr 2018) We are testing a new USB +5/-5V power supply. For ECE 2074, you can check out an USB power supply to test it. The checked out item must be returned. ECE 2054, ECE 2074, ECE 3074 Students are required to purchase or have the following Lab-in-a-Box items: RSR/VT A and D Trainer - Part no 32VPTADBRD from Electronix Express or another vendor. Velleman PCSGU250 Oscilloscope with Function Generator - Part no 32VPTPCSGU250 from Electronix Express or another vendor. Note: if you have a 1MHz scope with a function generator, you do not need to purchase the Velleman scope. Digital multimeter - MY64 Part no 01VPTMY64 from Electronix Express is recommended. Note: Other meters with similar specs are acceptable. Meter and scope probe kit - Part no 32VPTTPK2 from Electronix Express is recommended (32VPTTPK2 contains multiples of the cables below). need at least 1 - BNC to Test Hook, 3 ft. long (05SPAT1) need at least 1 - BNC to Alligators 10x scope probe, 3 ft long (05SPAK220) need at least 1 - Banana-to-IC Hook, , 1 black, 1 red, 3ft. long (05ALS5) need at least 1 - Banana-to-Alligators, 1 black, 1 red, 3ft. long (05ALS3) Screwdriver, 22 Gauge wire stripper, needle nose pliers - tool kit Part no 32VPTTK1 from Electronix Express is recommended. Similar tools are acceptable. LTspice - free download from Linear Technology   You do NOT need Pspice software or books! Do not purchase these items even if they are listed in the bookstore for these classes! ECE 2054 and 2074 Students will receive from the ECE Dept: Electronics Parts Kit with all electronic circuit components (resistors, capacitors, inductors, diodes, transistors ICs, etc) Distribution is in the OpEL Lab (219 Whittemore) during the second week of classes. ECE 3074 Students should already have: Electronics Parts Kit with all electronic circuit components (resistors, capacitors, inductors, diodes, transistors ICs, etc) Replacement kits may* be issued if you sold or lost your kit. (*If we have spare kits) Transfer students should contact your instructor to obtain a kit.

Page updated: Jan 24th, 2018
